Factory Aluminum Coil 1060 H24 Metal Sheet Roll 3003 H14 H22 Roll Low Price Aluminum Coil
The most common type is A91100 which is commercially pure aluminum. It is soft and very ductile, having excellent workability. Well suited for applications involving severe forming as it work hardens more slowly during forming. It is the most weldable of all aluminum alloys.
Aluminum comes in three basic types: 1100, 3003, and 6061. The grade of the aluminum will determine the end-use application and price point. For example, 1100 is a lower-cost material than 6061 but cannot be used for high-temperature applications like cooking utensils or pot lids.
| 1)1000 Series Alloy (Generally called commercial pure aluminum,Al>99.0%) |
| Purity | 1050 1050A 1060 1070 1100 |
| Temper | O/H111 H112 H12/H22/H32 H14/H24/H34 H16/
H26/H36 H18/H28/H38 H114/H194, etc. |
| Specification | Thickness≤30mm; Width≤2600mm; Length≤16000mm OR Coil (C) |
| Application | Lid Stock, Industrial Device, Storage, All Kinds of Containers, etc. |
| Feature | Lid Shigh conductivity, good corrosion resistant performance, high latent heat
of melting, high-reflectance, well welding property, low strength, and not
suitable for heat treatments. |
1100 aluminum coil properties
| Alloy Temper | Specified | Tensile strength | Yield strength | Elongation |
| Thickness(in.) | (KSI) | (KSI) | (%) |
| 1100-O (annealed) | 0.006-0.019 | 11.0-15.5 | Min3.5 | Min15 |
| 0.020-0.031 | Min20 |
| 0.032-0.050 | Min25 |
| 0.051-0.249 | Min30 |
| 0.250-3.000 | Min28 |
| 1100-H12/1100-H22 | 0.017-0.019 | 14.0-19.0 | Min11.0 | Min3 |
| 0.020-0.031 | Min4 |
| 0.032-0.050 | Min6 |
| 0.051-0.113 | Min8 |
| 0.114-0.499 | Min9 |
| 0.500-2.000 | Min12 |
| 1100-H14/1100-H24 | 0.009-0.012 | 16.0-21.0 | Min14.0 | Min1 |
| 0.013-0.019 | Min2 |
| 0.020-0.031 | Min3 |
| 0.032-0.050 | Min4 |
| 0.051-0.113 | Min5 |
| 0.114-0.499 | Min6 |
| 0.500-1.000 | Min10 |
| 1100-H16/1100-H26 | 0.006-0.019 | 19.0-24.0 | Min17.0 | Min1 |
| 0.020-0.031 | Min2 |
| 0.032-0.050 | Min3 |
| 0.051-0.162 | Min4 |
| 1100-H18/1100-H28 | 0.006-0.019 | Min22.0 | - | Min1 |
| 0.020-0.031 | Min2 |
| 0.032-0.050 | Min3 |
| 0.051-0.128 | Min4 |
| 1100-H112 | 0.025-0.499 | Min13.0 | Min7.0 | Min9 |
| 0.500-2.000 | Min12.0 | Min5.0 | Min14 |
| 2.001-3.000 | Min11.5 | Min4.0 | Min20 |
1. Q: Are you a manufacturer or trading company?
A: We are a professional manufacturer with 1.5 million tons of aluminum annually in China. We have passed the factory inspection by various international organizations and have our own sales team. Welcome to seeing and inspecting our factory
2. Q: Do you have quality control system?
A: Yes,we have iso,bv,sgs certifications and our own quality contorl laboratory.
3. Q: How long is your delivery time?
A: Within 7-15 days after receiving the deposit or L/C at sight. Longer lead time will be required for special designed products.
4. Q: Do you provide samples ? is it free or extra ?
A:Yes, we could offer the sample for free charge but the delivery charges will be covered by our customers.
5. Q: Do you provide after-sale service?
A: We provide after-sales service and offer 100% guarantee on our products.
